The DCCZ 3-4 roaster

Chike Machinery miniature single-phase electromagnetic roasting machine for household and small window stores, output 3-10 kg per hour, a multi-purpose machine, 220V voltage for more places, electromagnetic heating technology, energy saving and environmental protection.

Cellphone：+86 15893717199

Send E-mail Get Price

Details

Model	Capacity	Roast time	Heating power	Motor power	Voltage	Overall size(mm)	Size of drum(mm)
DCCZ 3-4	5-10kg/h	15-30minutes	0.6-3KW/5grades	0.18kw	220V/50HZ Single phase	730X510X800	300x400

Main image

Electromagnetic roaster

Trade Terms

1.Price term: EXW,FOB,CIF,CNF,DDU

2.Materials: Main body 304# Stainless steel, the batch 430# Stainless steel.

3.Payment: TT,L/C,Paypal,Alipay,Wechat,Credit card.

4.Delivery time: supply in stock, production line need 20-30working days.

5.Working life: 8years.

6.Customized service: accept. MOQ: 5sets

7.Supply quantity: 100sets/month

8.Package: packing in ply wooden case.

9.Shipping term: by sea, by air and by train.

10.Warranty term: 2years.

11.Installation: If buyers need,Chike Machinery will send the engineers to customer's site.Chike Machinery will supply the instruction and video of installation for free.

Application

roast, heat and dry the materials as follow:

Nut processing: sunflower seeds,peanut,chestnut,soya bean, cashew nut,almond,walnut,etc.

Tea processing: tea leaf &Tartary buckwheat.

Chemical industry: heat and drying the chemical industry materials.

Condiments processing: chili,pepper,aniseed,etc.

Chinese medicine processing: medicine pieces

Feed processing: fish feeds powder.

Grain processing: corn,broom corn,rice,millet,barley and wheat.

Roast nuts parameter list

Roast nuts parameter list(Just for reference)
Reference data	Cashew nut	Almond	Pistachio nut	Chestnut
Reference data
Salt	With/without salt	With/without salt	With/without salt	With sand
Temperature	170	165	175	155
Heating grade	P2	P2	P3	P3
Roasting time(minute)	20mins	18mins	25mins	30 mins
Capacity/barrel	5kg	5kg	5kg	3kg
